Name: Rail Lines

Display Field: Mode

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Regional rail line data obtained from NCTCOG and DART in the Fall of 2023. SOURCES:NCTCOG Regional Data Center -- to download shapefiles for Transit Stops, Transit Routes, Existing Rail Stations, and Existing Rail Lines (https://data-nctcoggis.opendata.arcgis.com/search?q=DART)DART Contact: Linicha Hunter, Project Manager for Plano, LHunter@dart.org

Copyright Text: NCTCOG, DART, BI/GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2325338.061964214
YMin: 6925130.616605401
XMax: 2562792.3908603936
YMax: 7127156.979612231
Spatial Reference: 102738  (2276)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Line
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Blue
  Label: Blue Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 92, 230, 255]
  Width: 4
• Value: Green
  Label: Green Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [76, 230, 0, 255]
  Width: 4
• Value: Orange
  Label: Orange Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 152, 0, 255]
  Width: 4
• Value: Orange Peak
  Label: Orange Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 152, 0, 255]
  Width: 4
• Value: Red
  Label: Red Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 0, 0, 255]
  Width: 4
• Value: Red Peak
  Label: Red Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 0, 0, 255]
  Width: 4
• Value: Silver (Future)
  Label: Silver (Future) Line
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [196, 196, 196, 255]
  Width: 3
• Value: Trinity Railway Express
  Label: Trinity Railway Express
  Description: N/A
  Symbol:
  Style: esriSLSDashDot
  Color: [0, 0, 0, 255]
  Width: 0
• Value: TRE
  Label: Trinity Railway Express
  Description: N/A
  Symbol:
  Style: esriSLSDashDot
  Color: [0, 0, 0, 255]
  Width: 0
• Value: A-train
  Label: A-train
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [223, 115, 255, 255]
  Width: 3
• Value: TEXRail
  Label: TEXRail
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [115, 223, 255, 255]
  Width: 3
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID_1 )
• Mode ( type: esriFieldTypeString, alias: Mode, length: 13 )
• Line ( type: esriFieldTypeString, alias: Line, length: 23 )
• Agency ( type: esriFieldTypeString, alias: Agency, length: 18 )
• StationA ( type: esriFieldTypeString, alias: StationA, length: 38 )
• StationB ( type: esriFieldTypeString, alias: StationB, length: 38 )
• Year_Opened ( type: esriFieldTypeString, alias: Year_Opened, length: 4 )
• ShapeSTLen ( type: esriFieldTypeDouble, alias: ShapeSTLen )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
