Name: Survey Monuments

Display Field: STATION_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This feature class contains all the survey monuments in the City of Plano, including links to the individual datasheets stored in CivicPlus. The City of Plano has contracted with multiple consulting firms to establish geodetic control monuments, and then to update, check, and validate the network integrity over time. Plano has most recently contracted with Gorrondona & Associates (G&AI) in 2008-2009 to provide professional surveying services, and G&AI submitted an updated survey report in 2023. G&AI provided the updated data as well as the updated individual datasheets for each survey monument. The final control survey report from G&AI dated 11/9/2023 is saved here:https://www.dropbox.com/scl/fi/dcoyq16zryq4ik7a02aki/2023_City-of-Plano-Control-Survey-Final-Report_11-09-23.pdf?rlkey=w6g19tcbqdf5y2bvhmhikeovw&dl=0Last Updated: December 2023

Copyright Text: Gorrondona & Associates, Inc. (G&AI), Halff Associates, Analytical Surveys, City of Plano Engineering, City of Plano BI/GIS

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2472942.9416424483
YMin: 7048847.519974902
XMax: 2546888.690062791
YMax: 7096124.409946293
Spatial Reference: 102738  (2276)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• POINT_NUM ( type: esriFieldTypeString, alias: POINT_NUM, length: 255 )
• VRS_GRID_NORTHING ( type: esriFieldTypeDouble, alias: VRS_GRID_NORTHING )
• VRS_GRID_EASTING ( type: esriFieldTypeDouble, alias: VRS_GRID_EASTING )
• NAVD88_ELEVATION ( type: esriFieldTypeDouble, alias: NAVD88_ELEVATION )
• DESCRIPTION ( type: esriFieldTypeString, alias: DESCRIPTION, length: 255 )
• DESIGNATION__STAMPING_ ( type: esriFieldTypeString, alias: DESIGNATION__STAMPING_, length: 255 )
• STATION_NAME ( type: esriFieldTypeString, alias: STATION_NAME, length: 255 )
• GPS_POINT__ ( type: esriFieldTypeSmallInteger, alias: GPS_POINT__ )
• NAD83HARNGRIDNORTHING ( type: esriFieldTypeDouble, alias: NAD83HARNGRIDNORTHING )
• NAD83HARNGRIDEASTING ( type: esriFieldTypeDouble, alias: NAD83HARNGRIDEASTING )
• NAVD88ELEVATIONHARN ( type: esriFieldTypeDouble, alias: NAVD88ELEVATIONHARN )
• DESCRIPTION_ ( type: esriFieldTypeString, alias: DESCRIPTION_, length: 255 )
• ESTABLISHED_BY ( type: esriFieldTypeString, alias: ESTABLISHED_BY, length: 255 )
• CONDITION ( type: esriFieldTypeString, alias: CONDITION, length: 255 )
• PUB_MEAS_DELTA_NORTHING ( type: esriFieldTypeDouble, alias: PUB_MEAS_DELTA_NORTHING )
• PUB_MEAS_DELTA_EASTING ( type: esriFieldTypeDouble, alias: PUB_MEAS_DELTA_EASTING )
• PUB_MEAS_DELTA_ELEVATION ( type: esriFieldTypeDouble, alias: PUB_MEAS_DELTA_ELEVATION )
• STATION_NAME_ ( type: esriFieldTypeString, alias: STATION_NAME_, length: 255 )
• DATE_ESTABLISHED ( type: esriFieldTypeString, alias: DATE_ESTABLISHED, length: 255 )
• COUNTY ( type: esriFieldTypeString, alias: COUNTY, length: 255 )
• MARK_LOGO ( type: esriFieldTypeString, alias: MARK_LOGO, length: 255 )
• NAD83_NSRS2007_GRID_NORTHIN_23 ( type: esriFieldTypeDouble, alias: NAD83_NSRS2007_GRID_NORTHING )
• NAD83_NSRS2007_GRID_EASTING ( type: esriFieldTypeDouble, alias: NAD83_NSRS2007_GRID_EASTING )
• NAVD88_ELEVATIONNSRS ( type: esriFieldTypeDouble, alias: NAVD88_ELEVATIONNSRS )
• NORTH_LATITUDE ( type: esriFieldTypeString, alias: NORTH_LATITUDE, length: 255 )
• WEST_LONGITUDE ( type: esriFieldTypeString, alias: WEST_LONGITUDE, length: 255 )
• ELLIPSOID_HEIGHT ( type: esriFieldTypeDouble, alias: ELLIPSOID_HEIGHT )
• GEOID_HEIGHT ( type: esriFieldTypeDouble, alias: GEOID_HEIGHT )
• PLANO_SURFACE_NORTHING ( type: esriFieldTypeDouble, alias: PLANO_SURFACE_NORTHING )
• PLANO_SURFACE_EASTING ( type: esriFieldTypeDouble, alias: PLANO_SURFACE_EASTING )
• NAD27_NORTHING ( type: esriFieldTypeDouble, alias: NAD27_NORTHING )
• NAD27_EASTING ( type: esriFieldTypeDouble, alias: NAD27_EASTING )
• NGVD29_ELEVATION ( type: esriFieldTypeDouble, alias: NGVD29_ELEVATION )
• URL ( type: esriFieldTypeString, alias: URL, length: 255 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
