Name: Sign Toppers

Display Field: STREET

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This feature class contains the regulatory signs in the City of Plano. This data was created in fall of 2016, and has been edited on regular basis by Public Works staff via Cartegraph application.

Copyright Text: Data was originally field collected, and is currently maintained by Public Works.

Default Visibility: false

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2471049.1087961346
YMin: 7050059.506182805
XMax: 2546865.77999714
YMax: 7097124.984230146
Spatial Reference: 102738  (2276)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [115, 76, 0, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[130, 130, 130, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• X ( type: esriFieldTypeDouble, alias: X )
• Y ( type: esriFieldTypeDouble, alias: Y )
• STREET ( type: esriFieldTypeString, alias: STREET, length: 50 )
• MUTCDCODE ( type: esriFieldTypeString, alias: MUTCDCODE, length: 20 )
• SIGNTEXT ( type: esriFieldTypeString, alias: SIGNTEXT, length: 250 )
• IMAGE ( type: esriFieldTypeString, alias: IMAGE, length: 50 )
• CONDITION ( type: esriFieldTypeString, alias: CONDITION, length: 4 , Coded Values: [GOOD: GOOD] , [FAIR: FAIR] , [POOR: POOR] )
• SIGNFACEDIRECTION ( type: esriFieldTypeString, alias: SIGNFACEDIRECTION, length: 10 , Coded Values: [N: NORTH] , [E: EAST] , [S: SOUTH] , ...5 more... )
• TRAVELDIRECTION ( type: esriFieldTypeString, alias: TRAVELDIRECTION, length: 20 , Coded Values: [N: NORTH] , [E: EAST] , [S: SOUTH] , ...5 more... )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 250 )
• SUPPORTTYPE ( type: esriFieldTypeString, alias: SUPPORTTYPE, length: 50 , Coded Values: [WOOD POLE: WOOD POLE] , [BRIDGE: BRIDGE] , [U-CHANNEL: U-CHANNEL] , ...7 more... )
• CONDITIONINDEX ( type: esriFieldTypeSmallInteger, alias: CONDITIONINDEX )
• INSTALLYEAR ( type: esriFieldTypeSmallInteger, alias: INSTALLYEAR )
• SUPPORT_ID ( type: esriFieldTypeInteger, alias: SUPPORT_ID )
• MUTCDTYPE ( type: esriFieldTypeString, alias: MUTCDTYPE, length: 25 , Coded Values: [R: REGULATORY] , [W: WARNING] , [G: GUIDE] , ...3 more... )
• CARTEGRAPH_ID ( type: esriFieldTypeString, alias: CARTEGRAPH_ID, length: 50 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• INSPECTIONDATE ( type: esriFieldTypeDate, alias: Inspection Date, length: 8 )
• SignOwner ( type: esriFieldTypeString, alias: Sign Owner, length: 50 )
• RETIRED ( type: esriFieldTypeDate, alias: Retired, length: 8 )
• REPLACED ( type: esriFieldTypeDate, alias: Replaced, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• ElementaryAttendanceZone ( type: esriFieldTypeString, alias: Elementary Attendance Zone, length: 50 )
• MiddleAttendanceZone ( type: esriFieldTypeString, alias: Middle Attendance Zone, length: 50 )
• HighAttendanceZone ( type: esriFieldTypeString, alias: High Attendance Zone, length: 50 )
• SeniorHighAttendanceZone ( type: esriFieldTypeString, alias: Senior High Attendance Zone, length: 25 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
